4' LED High Bay with diffuse lens
Illumadyne’s Cool-LED Lensed High Bay (CLLHB) is a powerful package of aluminum-core light bars, high efficacy LEDs, and multiple lensed distribution options. With efficacies up to 200 lumens per watt, maximum energy savings will be achieved while providing quality lighting to meet your application.
4CB
Highlights
LED SYSTEM: Illumadyne has elected to use the latest 3030 and 2835 mid-power LED’s from Samsung, achieving efficiencies of up to 200 LPW. We configure our linear LED Boards for the optimum in efficiency and thermal management through the use of all Aluminum PCB’s. When combined with the latest high efficiency drivers and our LED Modules, Illumadyne is able to achieve over 165 Lumens/Watt for system efficacy (Including Driver Loss), while providing a modular concept for scalability. All drivers are equipped with short circuit and over temp protection.
OPTICAL SYSTEM: Through the use of our novel “Floating” Specular Reflector design, Illumadyne can effectively manipulate the distribution pattern of our fixtures without the high cost of optical lenses. Available with a clear Acrylic Glass Lens to limit dirt depreciation.
- > 165LPW
- > 80 CRI
- Mid Power LED’s Reduce Glare and Improve Visual Comfort
- Standard with 0-10v Dimming Driver
- Integral PIR & Microwave Sensor Available
- Lifetime - L70 of 140,000 hrs at 50C
- Limited 7-Year Warranty
4CB
Details
- Screw fasteners, All Aluminum Construction
- Low-profile, lightweight design provides ease of installation
- Surface Mount or Aircraft Cable Hanger Assembly
- Boxed End Enclosures for added Rigidity
- Suitable for Damp Locations
- ETL & DLC Listed
